Hamfest Raffle Prize Winners 2023

	Prize	Callsign	Name
Grand Prize	FT-DX10	K9ANI	Eugene Neigoff
2nd Place	FT-5DR	KG7COA	Joe Soubie
3rd Place	DB-750X	KD7DJG	Stephen Hall
4th Place	AT-D878	KK7FYB	Susan Gray
5th Place	ClearNode	KG7MMD	Russell Gill

*CLOSED* Purchase Raffle Tickets Online *CLOSED*

Raffle Ticket Sale locations:

All day at the Hamfest on January 14, 2023

Copafest on October 28,2022

Monthly TBARC General Meetings at Arizona Christian University

Raffle Drawing

The Raffle Drawing will be on January 14th, at the Hamfest at noon (Ticket sales end 11:30 AM)
Prizes will be drawn in reverse order (5th Place first) and will include 5 alternates
Winners have 30 days to claim their prize

Raffle Prizes:

Official Raffle Rules

Raffle Prize Descriptions:

Yaesu FT-DX10 HF/50MHz 100W SDR

SDR HF Technical Support option 8 (NEW)

We are pleased to introduce the FTDX10, a new long-awaited compact HF/50MHz 100W SDR Transceiver!

Hybrid SDR Configuration

Like the FTDX101 series, the new FTDX10 utilizes the Yaesu Hybrid SDR configuration – Narrow Band SDR and Direct Sampling SDR. The Narrow band SDR receiver emphasizes excellent receiver performance, while the Direct Sampling SDR provides a Digital Processing Real-Time Spectrum Scope.

Narrow Band SDR with 3 types of Roofing Filters and Phenomenal Multi-signal receiving Characteristics

Like the FTDX101 series, the Down Conversion type receiver configuration with the first IF at 9MHz has been adopted.  It makes it possible to incorporate excellent narrow bandwidth crystal roofing filters that have the desired sharp “cliff edge” shape factor.  Thanks to the Narrow Band SDR with the latest circuit configuration including 500Hz, 3kHz and 12kHz roofing filters and low-noise oscillator, the RMDR (Reciprocal Mixing Dynamic Range) reaches 116dB or more, the close-in BDR (Blocking Dynamic Range) reaches 141dB or more and 3rd IMDR (third-order Intermodulation Dynamic Range) reaches 109dB or more in the 14MHz band at 2kHz separation.

250MHz HRDDS (High Resolution Direct Digital Synthesizer) affords Quiet and Clear Reception

The local circuit of the new FTDX10 uses 250MHz HRDDS method same as the FTDX101 series.  Thanks to its characteristics that improve the C/N (carrier to noise) ratio and the careful selection of components in the design, the phase noise characteristic of the local signal achieves an excellent value of -145dB or less in 14MHz at 2kHz separation.

3DSS (3-Dimensional Spectrum Stream) on the 5-inch Full-Color TFT Display with Touch-Panel Functionality

The 5-inch Full-Color panel shows the 3DSS display.  By touching the frequency display, the numeric keypad is displayed, and the active band and frequency adjustment can be set by direct input.  Frequency setting and adjustment can also be performed by turning the MAIN dial or touching the scope display.  Similar to the FTDX101 series, the MULTI display, RX operation status display, Center, FIX and Cursor modes are available.

Front Panel Designed for Superior Operating Efficiency

MPVD (Multi-Purpose VFO Outer Dial), is a large multi-purpose ring around the outside of the VFO dial that enables control of Clarifier, C/S (custom selection function) and recall of memory channels.

Remote Operation with optional LAN unit (SCU-LAN10)

Remote operation of the transceiver is possible with the optional SCU-LAN10 and SCU-LAN10 Network Remote Control Software. In addition to controlling the transceiver basic operations, the versatile scope displays enable sophisticated operations such as monitoring the band conditions on a large display at a location away from the ham shack by connection to a home LAN network.

The features of the new FTDX10 include:

• 15 separate band pass filters
• Effective QRM rejection with the IF DSP (IF SHIFT/WIDTH, IF NOTCH DNF, DNR, COUNTOUR) High-quality and super stable final amplifier utilizing the new push-pull MOSFET RD70HUP2   Aluminum Heat Sink with 80mm low-noise axial flow cooling fan
• High Speed Automatic Antenna Tuner with a large capacity 100-channel memory
• RF & AF Transmit Monitor
• Microphone Amplifier with Three-stage parametric Equalizer (SSB/ AM mode)
• QMB (Quick Memory Bank)
• Band Stack Function
• Optional speaker – SP-30 designed for the new FTDX10
• Optional roofing filter (300Hz) – XF-130CN available

Yaesu FT-5DR Dual Band VHF/UHF

The new FT5DR is a full-featured C4FM handheld transceiver with superior operability and new sophisticated functions.

Even in a compact body (W2.44” x D1.34” x H3.94”), the FT5DR provides reliable 5W RF power output and achieves loud 1W audio power that has been tuned for quality audio. Real Dual Band Operations (V+V, U+U, V+U, U+V) are available with two independent receivers. Large individual LED indicators for A band and B band present the status and communication modes (C4FM or Analog) of each band instantly. The new FT5DR supports simultaneous C4FM digital (C4FM/C4FM standby).

With rubber protectionon the corner of the main body, the FT5DR has rugged and shock-resistant construction. The waterproof rating is IPX7. The comfortable size and form of the full-flat back body provides excellent grasp for the radio operator.

A high-resolution display highlights the frequency of the operational band. The color of the operating band frequency can be selected from white, blue or red. Three (3) touch panel keys and seven (7) operation keys below the display offer intuitive operability.

The new TOUCH & GO operation is convenient in order to immediately start the communications on an often-used frequency. By pressing and holding the “PMG” key, the frequency of the current display is registered into Primary Memory Group.  After registration, pressing the “PMG” key will display the receive status of the registered frequencies as bars on   a graph (activity monitor). By simply touching the displayed bar, the user can instantly recall that frequency. (TOUCH &  GO Operation)

Band Scope function monitors in real time, up to 79 displayed channels that are centered around the current VFO frequency. The center frequency can be tuned by the dial knob or by touching and moving the frequency of a displayed channel bar.

The C4FM digital communication features which are already popular in the market, such as: Automatic Mode Select (AMS), Digital Group ID (DG-ID) operation, and Smart Navigation function are available with the new FT5DR.

The FT5DR supports the WiRES-X Portable Digital Node Function as well. A portable digital node can be easily set up with the new FT5DR, an internet connected laptop PC, and the optional SCU-39 cable kit

Plus advanced features of the new FT5DR are: Wireless hands-free operation using the optional Bluetooth®headset (SSM-BT10); VOX function; Memory Auto Grouping (MAG); VFO Band Skip Function; Wide-range RX coverage with continuous reception from 0.5MHz–999.99MHz (A Band)* & 108MHz–580MHz (B Band)*; Built-in high-sensitivity 66 channel GPS receiver; 1200/9600bps APRS Data modem; 2,200mAh High-Capacity Li-ion Battery Pack (SBR-14LI) as standard; Voice Recording Function; Simultaneous AM/FM broadcast Reception while monitoring two frequency channels; Micro SD Card Slot.

New Quick Release Holster (SHB-26) is included in the FT5DR package as a supplied accessory that allows single-touch attaching and detaching the transceiver while wearing the holster on a belt.

Powerwerx DB-750X Dual Band VHF/UHF

Features

All of the features you want at an affordable price. The newest mobile added to the Powerwerx lineup features Narrow band transmit (2.5 KHz) except on the Amateur bands (selectable Wide or Narrow RX), true dual-band receive (V+V, U+U, V+U, U+V), Wide RX/TX 136-174/400-490 MHz, AM aircraft Receive 108-136 MHz and user selectable multi-colored LCD display. Since this is a Commercial Land Mobile Multi-band radio, the DB-750X ships keyboard locked. The PRG-750 or RPS-DB750X-USB programming cable is required to initially unlock and program this radio before use. Ideal for Fire, Police, FEMA, CAP, security patrols, business communications, schools, construction crews, universities, and other organizations that have FCC licensed frequencies. Includes 2.5 KHz channel step for FCC 2013 narrowband compliance. DB-750X Model Features 2.5 step for FCC 2013 narrowband compliance 750 memory channels 10 Memory Banks (with bank linking) 7 Character Alpha-Numeric Display Dual Receive Operation w/ separate Volume Controls Narrow band (2.5 KHz) operation for Land Mobile frequencies (FCC Part 90) Wide band (5.0 KHz) operation for Amateur frequencies Optional Base Station Configuration FCC Approval The DB-750X is Part 90 certified for commercial use. CE & FCC Part 90 certified. Powerwerx Warranty Policy 12 month limited warranty on the radio against defects in materials and workmanship Standard Accessories Included with Every Radio Dual band transceiver w/ removable control head DTMF Microphone DC Power Cable Mobile Mounting Bracket (w/ mounting screws) English user manual Features True Dual band Receive (VHF+UHF, VHF+VHF, UHF+UHF) 7 Character Dual alpha numeric, backlit display 4 Selectable high/low power settings per band (VHF: 50/20/10/5W) (UHF: 40/25/10/5W) Single or Dual Receive/Display Modes User selectable multi-colored LCD display 750 Memory Channels w/ 10 Banks

AnyTone AT-D878UVII Plus UHF/VHF/DMR

Anytone AT-D878UVII Plus Digital DMR Dual-band Handheld Commercial Radio with GPS, APRS RX/TX and Bluetooth

VHF/UHF Dual-band Digital/Analog Part 90 DMR commercial transceiver with 1.77 inch color TFT display Bluetooth and GPS. New AT-D878UVII PLUS model with green colored top button, includes DMR Roaming, larger memory for future enhancements and storage up to 500,000 contacts. Ideal for Fire, Search & Rescue, EMS, Police, Sheriff, Forestry and Security operations. Frequency coverage 140-174 / 400-480 MHz. Includes USB Programming cable and Bluetooth PTT button.

EXCITING NEW “D878UVII PLUS” FEATURES:

• Increased “Digital Contacts” capacity from 200,000 to 500,000
• New APRS RX feature with arrow pointing direction display
• Increased memory for future enhancements
• New top mounted “Green” colored button



Main Features:

Roaming

Built-in DMR Repeater Roaming feature

APRS / GPS Capable

DMR-APRS and Analog APRS Capable (GPS)

VHF/UHF Dual Band

Monitor two bands at the same time (V+V, U+U & V+U).

Digital DMR and Analog

Features both DMR digital and analog modes on any channel.

High Power Output

6.0W, 4.0W, 2.5W, 1.0W selectable TX power output.

Bluetooth

Bluetooth connectivity to some devices (see below)

Programming Cable

Includes USB Programming Cable, free software available for download.

Color TFT Display

1.77 inch color TFT screen for Day or Night operation. User changeable display and font colors.

Technical Specifications:

Bluetooth:	New Bluetooth feature compatible with many newer car entertainment systems and Bluetooth devices. It cannot be guaranteed that it will work with all of these devices. Anytone will continue improving the Bluetooth function to allow more device and car models in the future. No timeframe for these future Bluetooth updates is available.
Roaming:	New Built-in Roaming Feature
APRS (GPS):	DMR-APRS and Analog APRS Capable (GPS)
Processor:	Faster Processor over the D878UV D868UV models
Additional Memory:	Larger Memory for Future Enhancements
TFT Display:	Background Display and Font Colors are User changeable
Digital Monitor:	Monitor One or Two Timeslots
Zone Select:	Selectable Zones from Keypad
Auto RX Mode:	Receiver Auto Selects to incoming Digital or Analog Signal
GPS:	Built-in GPS feature
Memory Channels:	4,000 channels
DMR Talk Groups:	10,000
Digital Contacts:	500,000 (complete worldwide database from DMR-MARC)
Power Levels:	4 programmable power levels: 6/4/2.5/1 Watt Transmit Power Levels.
Zones:	250 zones, up to 250 channels per zone.
Display:	1.77 inch color TFT Screen with selectable dual channel or single channel display.
Battery:	Operate 35+ hours between charges with the supplied 3100 mAh lithium ion battery in the power saver mode.
Bandwidth:	12.5 / 25.0 kHz Analog, and 12.5 kHz DMR
Import/Export:	Enhanced CPS allows direct input and export of channels, digital IDs and talkgroups.
Industries:	Ideal for fire, search & rescue, EMS, police, sheriff, forestry, security patrols, business communications, schools, universities, and other organizations that have FCC licensed frequencies.
DMR Compatibility:	Supports both Tier I and Tier II operation, making it compatible with DMR repeaters that utilize two-slot TDMA technology.
Amateur Radio:	Also operational on amateur radio DMR networks and analog frequencies. Software importable worldwide amateur contact database.
Programmable:	FCC 47CFR90.203 requires the keypad locked in the shipping configuration. Software keypad unlocking and re-programming are available with the included USB Programming Cable.
Speaker Connection:	2-pin style Kenwood/Wouxun type earphone and speaker mic connection for a variety of accessories.
Quiet Tones:	CTCSS/DCS tone squelch with split tone and custom tone capability.
Frequency Range:	136-174 / 400-480 MHz RX/TX
Package Includes	Dual-band VHF/UHF Radio, 3100 mAh extended life lithium ion battery, desk charger w/ AC adapter, Dual-band antenna, belt clip, Bluetooth PTT button and charging cable, free USB Programming cable and downloadable software, user manual.
Certifications	FCC Part 90 Certified, FCC ID: T4KD878UV

Node Ventures ClearNode

ClearNode is a pre-configured Raspberry Pi based AllStar, EchoLink & Digital Modes simplex node with an integrated low power UHF (or VHF) FM radio transceiver. Digital modes now include DMR, P25, YSF, FCS and NXDN.

ClearNode includes a free companion iPhone and Android mobile app to Setup and Control your node – from anywhere you have an internet connection.

You can also control your node connections using DTMF commands from your handheld radio.

The ClearNode Mobile App allows you to:

• Configure your AllStar, EchoLink & Digital credentials and settings
• Configure your ClearNode WiFi credentials without using SSH and Terminal
• Connect and disconnect your ClearNode from remote nodes, hubs, reflectors and Talk Groups
• Automate your connects and disconnects with calendar Timed Events
• Keep, edit and tag a catalog of the nodes you regularly connect to
• Control the integrated radio: Tx/Rx frequency, CTCSS/DCS codes, Squelch, Volume …
• Power down or reboot your ClearNode
• Play a delayed stream (~20 sec) of the audio traffic on your ClearNode on your mobile device
• Update the software revisions running on your ClearNode
• Find your ClearNode’s current LAN/WAN IP Address
• Control multiple AllStar & Echolink ClearNodes
